PARTS DIAGRAM:
Item Description Part No.
1 Chassis VSK2CH
2 Gearbox VNXK2GB
3 Motor VSK2MO
4 Brush Kit VAMBK
5 Electronic Positioning Sensor 2 (EPS2) VNXSLEPS2
6 Sprocket VAL3SP17
7 Idler Pulley DSIP10
8 Idler Bushing DSIB10
9 Manual Release Switch DUMRS10
10 Power Switch DUMRS10
11 Solar Charger VSCHARGSL
12 Solar Terminal Block Assembly VSTBASL
13 Solar Battery Breaker VASBB25
14 Solar Panel Switch DUMRS5
15 Solar Control Board VSPCBU18
16 Alarm DUAL10
17 Lock Cylinder & Key(s) VNXSLCL
18 Operator Cover VNXK2CV
19 Fuse - 4 amp VNXF4A
20 Fuse - 15 amp VNXF15A
21 25’ #40 Chain Kit, Nickel Coated VAL3CKN
22 Motor Harness VNXK2MH
