VIKING TECHNICAL SUPPORT 1.800.908.0884
13
! CAUTION: To Reduce the Risk of Fire or Injury to Persons:
! WARNING: For use with gates at a maximum 600 lbs. in weight or 14 ft. in length.
Specications:
Power Requirements: 115VAC / 230VAC (1.5* Amp / 1.0* Amp)
*Each Gate Operator
Single Phase (50Hz / 60Hz)
Alternative Power 24VAC / VDC (60VA) or Solar
Operating Temperature: -20°F (-28°C) to 160°F (71°C)
Maximum Gate Length: 14 ft.
Maximum Gate Weight: 600 lb.
IMPORTANT INSTALLATION INFORMATION
Locate Control Buttons:
1.
Within sight of the gate,
2.
At a minimum height of 5 feet
so small children are not able to
reach it; and
3.
At least 6 feet away from all
moving parts of the gate.
DO NOT allow pedestrian use of this gate DO NOT install the gate operator to lift gates
14 ft.
600 lb.
