TROUBLESHOOTING
# LED Status Meaning
Page 41
TS Ref#(s)
9 “C Loop” OFF Normal Condition.
SOLID An input from a device connected to the C Loop terminal. (pg 32, 42)
9, 10
10 “Open” OFF Normal Condition.
SOLID An input from a device to Exit, Fire, Strike or Open terminal. (pg 31, 42)
9, 10
11 “STOP” OFF Normal Condition.
SOLID Control Board is receiving an input from a device connected to the
Stop terminal. (pg 31, 42)
9, 10
FLASHING There is a problem with the required monitored sensor(s) connected to
the “UL” input terminal. (pg 10-11) 16, 22
12 “Close” OFF Normal Condition.
SOLID An input from a device connected to the Close terminal. (pg 31, 42)
9, 10
13 “Siren” OFF Normal Condition.
SOLID Second consecutive obstruction has been detected. (pg 25, 27)
11, 13, 1, 2
FLASHING Batteries are critically low.
1, 2
14 “Aux. Pwr” OFF No voltage output on these terminals at the moment.
SOLID There is 24V DC output on these terminals at the moment.
15 “Diagnose” (master) OFF Normal Condition
FLASHING Errors have been detected; Check LCD Display for ERR messages. (pg 40)
16
“Close Limit” (master) OFF Gate is not at the close limit position.
SOLID Gate is at the close limit position.
FLASHING Indicates a problem with the limit switches or wires.
6
17 “Open Limit” (master) OFF Gate is not at the open limit position.
SOLID Gate is at the open limit position.
FLASHING Indicates a problem with the limit switches or wires.
6
18 “ODS” OFF Normal Condition.
SOLID Obstruction event has been detected on the MASTER motor. (pg 25, 27)
11, 13, 1, 2
FLASHING Overload event has been detected on the MASTER motor. (pg 25, 27)
11, 13, 1, 2
19 “Timer” OFF If gate is at the open limit, the Timer to close is turned OFF. (pg 25)
SOLID Timer to close is ON and counting down to close the gate. (pg 25)
FLASHING TimerisONbutisnottimingoutduetoaconictingcommand.(pg25)
9, 10
S1 “Diagnose” (slave) OFF Normal Condition
FLASHING Errors have been detected; Check LCD Display for ERR messages. (pg 40)
SOLID Obstruction event has been detected on the SLAVE motor. (pg 25, 27)
11, 13, 1, 2
RAPID FLSH Overload event has been detected on the SLAVE motor. (pg 25, 27)
11, 13, 1, 2
S2 “Limit Close” (slave) OFF Slave gate is not at the close limit position.
SOLID Slave gate is at the close limit position.
FLASHING Indicates a problem with the limit switches or wires on the slave operator.
6
S3 “Limit Open” (slave) OFF Slave gate is not at the open limit position.
SOLID Slave gate is at the open limit position.
FLASHING Indicates a problem with the limit switches or wires on the slave operator.
6
E1
“AC VOLTAGE INPUT”
SOLID Normal Condition.
OFF IncomingpowertotheEMIBoardisnotsufcient..(pg20)
1
E2
“PROTECTION WORKING”
SOLID Normal Condition.
OFF EMI Board is damaged and circuit is not protected . Replace EMI Board.
E3
“AC VOLTAGE OUTPUT”
SOLID Normal Condition.
OFF There is no output voltage from the EMI Board.
2
