42
CLEAN THE BOBBIN AREA
Turn off the main switch
1. Remove the presser foot, the bobbin cover
and bobbin.
2. Clean the feed teeth with the brush.
Cleaning Under the Bobbin Area
Turn off the main switch
After sewing several projects or any time you
notice an accumulation of lint in the bobbin case
area, the area under the bobbin case must be
cleaned.
1. Remove the needle, presser foot, bobbin
cover and bobbin.
2. Remove stitch plate by removing the
two screws in the stitchplate. Lift up the
stitchplate.
3. Lift the bobbin case upwards and remove it.
4. Clean the area with the brush or with a dry
cloth.
5. Put the bobbin case back into the hook race
so that the tip fi ts into the stopper.
To Next Page
