The camera symbol serves to link
the figures on the illustration pages
with the corresponding text
passages in the instruction manual.
4.1 General
These safety regulations must
be observed when working with
the machine.
Read the entire instruction
manual before using the
machine for the first time. Keep
the instruction manual in a safe
place for future reference.
Observe the operating and maintenance
instructions contained in the separate
engine instruction manual.
These safety precautions are essential for
your safety, however the list is not
exhaustive. Always use the machine in a
reasonable and responsible manner and
be aware that the user is responsible for
accidents involving third parties or their
property.
Make sure that you are familiar with the
controls and operation of the machine. In
particular, the user must know how the
work tools and engine can be stopped
quickly.
The machine must only be used by
persons who have read the instruction
manual and are familiar with operation of
the machine. The user should seek expert
and practical instruction prior to initial
operation. The user must receive
instruction on safe use of the machine
from the vendor or another expert.
During this instruction, the user should be
made aware that the utmost care and
concentration are required for working with
the machine.
1
3. Machine overview
1 Self-propulsion lever (forwards)
2 Handles
3 HB 445 R, HB 560, HB 585, HB 685:
Self-propulsion lever (reverse)
4 Upper handlebar
5 Release lever (height adjustment)
6 Handlebar
7 Tension lever (lateral adjustment)
8 Brake spur
9 Transport chassis
10 Plant protection disc
11 Hoes
12 Right impact protector
13 Carrying handle
14 Left impact protector
15 Spark plug socket
16 HB 445, HB 445 R:
Primer
17 Engine
18 Recoil starter rope
19 Throttle lever
20 Folding retainer (brake spur)
21 Transport chassis locking pin
22 Identification plate with serial number
1
4. For your safety
