Viking HB 445 - Mounting the Hoes: HB 560, HB 585, HB; Installing the Plant Protection Disc; Fuel and Engine Oil

0478 403 9800 H - EN
32
4
● Insert folding retainer (W) through the
bores and close the securing clip.
● Install the plant protection disc if
necessary. (Ö 7.14)
● Repeat the hoe mounting procedure on
the other side.
7.13 Mounting the hoes: HB 560,
HB 585, HB 685
● Place the tiller in the cleaning
position. (Ö 12.2)
Definition of hoes:
– Hoe (H):
dual-row hoe.
– Hoe (I):
single-row hoe.
1 HB 560, HB 585, HB 685
● Push protection ring (P) up to the stop
on drive shaft (3). The recesses in the
protection ring must engage on the
three locating lugs of the gearbox
housing (4).
● Position hoe (H) so that the shorter
shaft mount (1) faces the gearbox
housing and cutting edges (5) point
forwards. Arrows (6) on the hoe and the
arrow on gearbox housing (7) must
point in the same direction.
● Push hoe (H) onto drive shaft (3).
● Turn hoe (H) so that the bores in the
shaft mount and the drive shaft align.
2 HB 560, HB 585, HB 685
● Insert folding retainer (W) through the
bores and close the securing clip.
3 HB 585, HB 685
● Position hoe (I) so that the smaller
outer diameter of shaft mount (2) faces
the already mounted hoe (H) and
cutting edges (5) point forwards.
Arrows (6) on the hoe and the arrow on
gearbox housing (7) must point in the
same direction.
● Push hoe (I) into the already mounted
hoe (H).
● Turn hoe (I) so that the bores in both
hoes align.
4 HB 585, HB 685
● Insert folding retainer (W) through the
bores and close the securing clip.
HB 560, HB 585, HB 685
● Install the plant protection disc if
necessary. (Ö 7.14)
● Repeat the hoe mounting procedure on
the other side.
7.14 Installing the plant
protection disc
● Install plant protection disc (J) on the
outer hoe. Turn the plant protection disc
so that the bores in the disc and the hoe
align.
● Insert folding retainer (W) through the
bores and close the securing clip.
● Repeat this procedure on the other
side.
7.15 Fuel and engine oil
Engine oil:
Please consult the engine
instruction manual for the type of
engine oil to be used and the oil capacity.
Check the oil filling level at regular
intervals (see engine instruction manual).
Avoid exceeding or falling below the
correct oil level.
Screw on the oil tank cap properly before
operating the engine.
Strictly observe the assembly
instructions. In particular, observe
the installation sequence and install
protection rings, hoes and folding
retainers completely as described.
When installing the folding retainer,
strictly observe the correct direction
of insertion and positioning of the
securing clip, as shown. In the case
of incorrect or rotated installation,
the folding retainer may come loose
and be lost.
For good working results, the
cutting edges of the hoes must
point forwards (not towards the
handlebar) – observe arrow
markings.
14
When installing the folding retainer,
strictly observe the correct direction
of insertion and positioning of the
securing clip, as shown. In the case
of incorrect or rotated installation,
the folding retainer may come loose
and be lost.
Avoid damage to the machine
Top up engine oil before starting for
the first time. Use a suitable filling
aid when topping up the engine oil
and when refuelling (e.g. funnel).
15
16
