Viking HB 445 - 12. Maintenance; 12.1 Removing the hoes

ENNO
37
SVDASLSKTRHUSRHRBGUKETMKAZ
0478 403 9800 H - EN
During tilling, the reverse gear serves
exclusively to free the tiller more easily
when it has become stuck. Reverse gear is
not intended for tilling purposes.
Engaging self-propulsion (reverse):
● Move the tiller to the area to be tilled
with the engine stopped. (Ö 13.)
● Start the engine. (Ö 11.6)
● Hold the tiller firmly at the handles with
both hands.
● Actuate and hold the red self-
propulsion lever (reverse). (Ö 8.2)
The drive shaft with the installed work
tools begins to rotate and the tiller
moves backwards.
Disengaging self-propulsion (reverse):
● Release self-propulsion lever (reverse).
(Ö 8.2)
The drive shaft with the installed work
tools stops.
11.10 Tilling
During tilling, rotating hoes are used to
loosen the soil and prepare it for the
sowing, cultivation or care of plants.
● Move the tiller to the area to be tilled
with the engine stopped. (Ö 13.1)
● Fold in the transport chassis. (Ö 11.4)
● Start the engine. (Ö 11.6)
● Hold the tiller firmly at the handles with
both hands and maintain a secure
footing – note working area for
operator. (Ö 10.1)
● Actuate and hold self-propulsion lever
(forwards). (Ö 11.8)
The hoes start to rotate and tilling can
begin.
● After work is completed, disengage
self-propulsion (Ö 11.8), stop the
engine (Ö 11.7) and clean the machine
(Ö 12.2).
12.1 Removing the hoes
● Allow the machine (engine, gearbox) to
cool down completely.
● Place the tiller in the cleaning position.
(Ö 12.2)
● Removing the plant protection discs:
Fold open the securing clip of folding
retainer (1) and remove the folding
retainer. Remove plant protection
disc (2).
Risk of injury!
Ensure sufficient space between
the operator's body and the
handlebar before engaging self-
propulsion (reverse).
Risk of injury!
Only work in a forward direction.
Beware of obstacles (e.g. stone
slabs of paths), which must not be
run over.
12. Maintenance
Risk of injury:
Carefully read the section "For your
safety" (Ö 4.), particularly the
subsection "Maintenance and
repairs" (Ö 4.7), and follow all
safety instructions exactly before
performing any maintenance or
cleaning operations on the
machine.
Detach the spark plug
socket before performing
any maintenance or
cleaning operations.
The complete hoe set together with
the plant protection disc can be
removed from the drive shaft by
removing the folding retainer next
to the gearbox housing. For
assembly work on the hoes, follow
the instructions in the "Mounting the
hoes" (Ö 7.12), (Ö 7.13) and "Hoe
combinations" (Ö 10.3) sections.
28
