28
HB 445 R, HB 560, HB 585, HB 685:
For safety reasons, the relevant release
lever must be pressed before actuation of
the self-propulsion lever. This prevents
inadvertent actuation of a self-propulsion
lever. The black self-propulsion lever is for
the forward gear and the red self-
propulsion lever is for the reverse gear.
Danger of burns:
Do not touch hot surfaces. Gearbox
housing becomes extremely hot.
6. Standard equipment
Item Designation Qty.
A Basic unit 1
B Handlebar 1
C Transport chassis 1
D Brake spur 1
E Left impact protector 1
F Right impact protector 1
G HB 445, HB 445 R:
Hoe 4
H HB 560, HB 585, HB 685:
Dual hoe 2
I HB 585, HB 685:
Single hoe 2
J Plant protection disc 2
K Self-propulsion lever
(forwards) black 1
L HB 445 R, HB 560,
HB 585, HB 685:
Self-propulsion lever
(reverse) red 1
M Locking pin
(transport chassis) 1
N Tension lever 1
O Retaining clasp (chassis) 1
P Protection ring 2
Q Washer 1
R Hexagon nut M10 1
S HB 445:
Lock nut M6 1
T Flat head bolt M6 1
U Lock nut M6 1
V HB 445:
Cover 1
2
W HB 445, HB 445 R,
HB 585, HB 685:
Folding retainer 10x40
HB 560:
Folding retainer 10x40
6
4
X Retaining pin 1
Y Folding retainer 8x50 1
Z Cable tie 2
– Instruction manual 1
– Engine instruction
manual 1
Item Designation Qty.
