machine that have become illegible, check
the entire machine for wear and damage.
Replace all worn and damaged parts.
Note the following additional points when
storing the machine for prolonged periods
(over winter):
● Clean all external parts of the machine
with care.
● Empty the fuel tank and carburettor.
● Thoroughly lubricate/grease all moving
parts.
● Unscrew the spark plug (see engine
instruction manual) and pour approx.
3 cm³ of engine oil into the engine via
the spark plug hole. Turn the engine
several times with the spark plug
removed (pull the recoil starter rope).
● Screw the spark plug back in (see
engine instruction manual).
● Perform an oil change (see engine
instruction manual).
● Cover the engine and store the
machine in the normal position.
13.1 Transporting the tiller
1 Pulling or pushing the tiller:
● Set the brake spur to the highest
position. (Ö 11.5)
● Fold out the transport chassis. (Ö 11.4)
● Hold the tiller at both handles (1) and tilt
backwards until the machine is standing
on the transport wheels.
● Push or pull the tiller slowly (walking
pace).
On firm and level ground, push the
machine. On rough and uneven ground,
it is advisable to pull the machine.
2 Lifting or carrying the tiller:
● Check for secure seating of the upper
handlebar (height adjustment) and the
handlebar (lateral adjustment).
● Lift and carry the tiller with at least two
persons and always maintain a
sufficient distance from the hoes.
Lifting points:
Handles (1) and carrying handle (2)
3 Transporting the tiller on a load
floor:
● Always transport the tiller in the upright
position – on the transport chassis and
hoes. Never place the machine on its
side.
● To ensure stability, fold out the
transport chassis (Ö 11.4) and mount
the hoes (Ö 7.12), (Ö 7.13).
● Secure the tiller on the load floor using
ropes or straps to prevent it from
slipping.
Lashing points:
Transport chassis axle (3) and hoe
axle (4).
Fire hazard:
Keep the spark plug socket away
from the spark plug hole due to
danger of ignition.
13. Transport
Risk of injury!
Observe the safety instructions in
the "For your safety" section (Ö 4.),
especially the "Transport" section
(Ö 4.4).
Prior to transporting, stop the
engine, detach the spark plug
socket and put on suitable safety
clothing (safety shoes, gloves,
overall covering hands and legs).
Take weight into account! (Ö 18.)
31
Risk of injury!
Due to the heavy weight of the
machine, particular care must be
taken at steps, kerbs, sloping
ramps and other raised areas.
The user must always stand higher
than the machine, in order to avoid
being run over by the machine in
the case of loss of control – i.e.
push the machine down or pull the
machine up steps and slopes.
Do not push or pull the machine
over more than two or three steps.
Where there are more steps, carry
the tiller with the help of a second
person.
