Mounting the lower bar
1. Fold the lower bar (3) upwards.
2. Turn the lower tightening levers (5) clockwise to fasten.
3. Lock the tightening levers (5) by pressing them in the direction of the lower bar (3). The
tightening levers must be pulled tight and then positioned against the bar so that
tightening can be carried out with medium force. If this fails, continue to turn the
tightening lever clockwise, or loosen it by turning counter clockwise.
Mounting the upper bar
1. Fasten the upper bar (1) with the enclosed screws (2b), the washers (2a) and the upper
tightening levers (2) on the right and left of the lower bar (3). The release button (16)
must be located on the right in the mowing direction. Two positions are possible.
2. Turn the tightening levers (2) clockwise to fasten.
3. Lock the tightening levers (2) by pressing them in the direction of the bar (3). The
tightening levers must rest against the bar in such a way that tightening can be carried
out with medium force. If this fails, continue to turn the tightening lever clockwise, or
loosen it by turning counter clockwise (see small illustration).
Release the tightening levers (2+5) and fold the upper bar (1) and the lower bar
(3) together so that the device takes up less space. Make sure not to pinch the
machine cables while doing this.
Mounting the grass collection box
1. Clip the handle (13c) of the grass collection box (13) into the upper side of the grass
collection box (13).
2. Place the plastic tabs (13a) of the grass collection box (13) over the grass collection
box rods (13b).
Mulch kit
Attaching the mulch kit
1. Remove the grass collection box, if used.
