Villager Villy 3740 E - Operation

13
2. Lift the impact protection.
3. Slide the mulch kit (18) into place. The bracket (18a) snaps into place.
Removing the mulch kit
4. Push in the bracket (18a) on the mulch kit and remove the mulch kit (18).
Operation
The device must only be adjusted when the motor is switched off and the
blade is stationary. There is a risk of personal injury.
Switch off the apparatus, remove the ignition key ( 10) and wait for the blades
to come to a standstill
Mounting/removing the grass collection box
1. To mount the grass collection box (13), lift the impact protection (4) and suspend the
grass collection box (13) from both receptors.
2. Fold the impact protection (4) over the grass collection box (13). This will hold the
grass collection box in the correct position.
3. To remove the grass collection box (13), lift the impact protection (4) and remove the
grass collection box (13). Fold the impact protection (4) back over the device housing
(12).
Work may not be carried out using the device without the impact
protection or grass collection box. There is a risk of injury.
Filling level indicator
There is a filling level indicator ( 26) on the side of the grass collection box (
13).
Filling level indicator open:
Grass collection box empty.
Filling level indicator closed:
Grass collection box filled.
