10.3 Radio Transceiver Base Station + Wired relay actuator + Internal communication interface
10.3.1 Block diagram
ON
4
3
2
1
PROG
MODULO DI
COMUNICAZIONE
INTERNA
01931
RS232
3 4 5
6 7 8 9
21
C L SCFG
CFG GSM/CI
GSM
01941 COMUNICATORE GSM
CISYS
Programmable thermostat + Radio Transceiver Base Station with relay module for wired commands
GSM Communicator + Internal communication interface
Climate control system
Wired connection
Radio connection
Fig. 10.3.1
