NETWORKING AND PROTOCOLS
Protocols IPv4 (with DiffServ), SIP, TCP, UDP, HTTPS, TFTP, RTP, DHCP, SNMP,
STENTOFON CCoIP® , NTP
LAN protocols Power over Ethernet (IEEE 802.3 a-f)
VLAN(IEEE 802.1pq)
Network Access Control (IEEE 802.1x)
STP (IEEE 802.1d)
RSTP (IEEE 802.1d-2004)
Management and operation HTTP/HTTPS (Web configuration)
DHCP and static IP + STENTOFON Pulse™
Remote automatic software upgrade
Centralized monitoring
Advanced supervision functions E.g. network test, tone test, status reports
SIP support RFC 3261 (SIP base standard)
RFC 3215 (SIP refer)
RFC 2976 (SIP info)
DTMF support RFC 2833, 2976 (SIP info)
ENVIRONMENT AND COMPLIANCES
IP rating IP-66, tested according to EN 60529
IK rating IK 08, tested according to EN 62262
Operating temperature range -25° to 70° C / -13° to 158 ° F
Storage temperature range -25° to 70° C / -13° to 158 ° F
Relative humidity < 95% non-condensing
Corrosion Salty mist, tested according to EN60945
Vibration Tested according to EN60945
UV-resistant YES
EMC CE and FCC Part 15
Compliances IEC/EN 60945 Marine Equipment
IEC/EN 6000-1 EMC Light Industry
IEC/EN 50155 Railway Application
IEC/EN 50486 Equipment for use in audio video door-entry systems
OTHER SPECIFICATIONS
System boot time Under 10 seconds
IP address information Speaks IP address after system boot
MTBF (mean time between failure) Value from final calculation
Country of manufacture Norway
