Turbine Station Conguration Guide
A100K11194
12 TurbineStationSpecications
The technical specications apply to the Turbine Compact IP Station
series: TCIS-1/ TCIS-1-V, TCIS-2, TCIS-3, TCIS-4, TCIS-5, TCIS-6.
AUDIO
Audio quality - speech transmission index (STI) - at 70 dB > 0.8*
Audio quality - percentagearticulationloss ofconsonants (Alcons)
- at 70 dB
< 5%*
Audio quality - total harmonic distortion + noise, without noise
reduction (THD+N) - at 70 dB
< 2%*
SPL rated power at 1m in open duplex 95 dB*
SPL rated power at 1m in half duplex 105 dB*
SPL rated power at 1m in program distribution and announcement 105 dB*
Noise cancelling - suppression of musical noise YES
Noise cancelling - suppression of static noise YES
Noise cancelling - suppression of rapidly changing noise YES
Codecs G.711, G.722
Frequency range, G.722 Codec 200 Hz – 7000 Hz
Audio technology Modes: Full open duplex, switched open duplex
Adaptive jitter filter
Local tone generator
Audio mixing - 3 channels
Sound level detection(scream alarm)
Automatic gain control (microphone)
Internal speaker amplifier 10 W class D
Microphone technology Digital MEMS, omnidirectional microphone
*Tested with Audio Precision SYS 2722 equipment
HARDWARE
Ethernet connector 1 x RJ-45
All other connectors Tool less, spring loaded, vibration proof terminals
General inputs and outputs 6 (configurable)
Outputs 12mA as LED drivers
Change-over relay (NO+NC+COM) Max: 250VAC/220VDC, 2A, 60W
Power options PoE and or external power supply
PoE (power over Ethernet) IEEE 802.3af standard, Class 0 (0.44W to 12.95 W)
External power supply 24 VDC (16 – 48 V)
Power consumption Idle 1W, max 12W (depending on volume)
Audio Line out / Induction loop signal 600 Ohm
Button backlight LED
Call indication Icons / colors according norm for hearing impaired
Door open indication Icons / colors according norm for hearing impaired
*Display technology PMOLED
*Display contrast 20000:1
*Viewing angle 160 deg
*Display brightness 120 cd/m2
*Display lifetime 100000 hours (11.5 years)
* Applies to Turbine models TCIS-4, TCIS-5, TCIS-6
CONSTRUCTION
Dimensions (HxWxD) 180 x 120 x 48 mm / 7.1” x 4.7” x 1.9”
Dimensions after flush mount 180 x 120 x 18 mm / 7.1” x 4.7” x 0.7”
Dimensions with on wall box 180 x 120 x 55 mm / 7.1” x 4.7” x 2.2”
Weight 1 kg / 2.2 lbs.
Faceplate material 3 mm / 0.12” stainless steel - AISI 403
Faceplate material 3 mm / 0.12” PMMA, anti reflective coating, color printed on
backside
Base / frame material 3 mm / 0.12” Aluminum alloy - A413.0, AlSi12Se, anodized
and painted
Electronics cover material Polycarbonate (translucent)
Gasket material Silicone rubber
Fastening bracket material SECC Steel
Button material 3 mm / 0.12” PMMA
Button travel length 1.25 mm
Button activation force 350 gf
Button push-cycles before failure 300 000
Vandal resistant fasteners Stainless steel, security TORX (with pin), T25
Loudspeaker poke protection, large diameter object 3D cast aluminum speaker grille
Loudspeaker poke protection, small diameter objects Stainless steel mesh, acoustically transparent
