Pro-6 HDVM system
13 The Pro-6 HDVM system utilizes a mid-level spreader (Fig 1.3) which fastens to the attachment points
(26). There are two spread settings, controlled by a knob (28), and the arm lengths can be adjusted using the
extension clamps (29) to compensate for uneven ground. A set of three feet (32) are also supplied with this
Fig 1.2 Pozi-Loc Tripod and Floor Spreader
(20)
(21)
(22)
(23)
(25)
(24)
(26)
(27)
