system to protect floors and carpets and prevents the tripod sinking into soft ground. The feet are secured to
the tripod by rubber straps (33).
NOTE: Always use the spreader where possible as this increases rigidity of the tripod. Adjustable
extension clamps compensate for uneven ground.
The spreader can be removed and a dolly fitted.
At the fullest extension of the spreader and with all legs fully retracted, the tripod can be
used at its lowest operating height. Although the tripod can be set up lower than this
without the spreader, it is NOT recommended as the tripod geometry becomes unstable
Fig 1.3 Pozi-Loc Tripod and Mid-level Spreader
(26)
(31)
(29)
(32)
(28)
(30)
(33)
