Tripod and mid-level spreader
5 To install the mid-level spreader (Fig 1.3):
5.1 Grip the ends of each spreader arm in turn between thumb and fore-finger and press in both
attachment release buttons (30).
5.2 Push the arm into the tripod attachment (26) ensuring the attachment pins (31) engage.
5.3 Secure the carpet feet (32) onto the tripod feet using the rubber straps (33).
5.4 To remove the spreader, press in the attachment release buttons (30) and free each arm in turn.
6 To adjust the mid-level spreader:
6.1 There are two spread settings. To select maximum (flat) spread, lift the spreader centre moulding
such that lugs can pass the extension arms, and rotate the spread knob (28) fully clockwise. To select
minimum (60°) spread, lift the spreader centre moulding and rotate the spread knob (28) fully
anticlockwise.
6.2 Extension arms can be individually adjusted by releasing the extension clamps (29), extending
the arm as required and re-tightening the clamp (29).
7 To adjust the tripod:
7.1 Adjust the operating height by undoing the leg clamps (21) and pulling the tripod up to the
desired height. Adjust the spreader (29) if necessary.
7.2 Tighten the clamps (21) until an audible click is heard and the knob is in the horizontal, locked
position.
WARNING!: Stability is reduced when the tripod is fully extended with the floor
spreader in the closed position. Use with care.
NOTE: The carpet feet attach using rubber straps in the same way as the floor spreader (23).
NOTE: The spread knob (28) will not rotate when the spreader is loaded. Lift the spreader centre
moulding to allow the knob (28) to rotate freely.
A pointer on the knob (28) indicates maximum or minimum spread setting.
NOTE: Do NOT attempt to fold the tripod if the spreader extension arms are uneven lengths. The
spreader may be damaged.
Set all extension arms to the same length (29) and then fold the tripod.
