Use the arrow buttons [ ] to select the desired
video and press the button [ ] to play.
1. Auto Event Detection
The camera will automatically record a video sequence
while a moving object is being detected during parking
mode. It will stop recording when no new movement is
detected.
There are three options for parking mode.
The camera has a HDMI out port for connecting an
external display such as a monitor or TV. You can use a
Micro HDMI to HDMI cable to connect the dashcam to a
monitor, allowing it to display the dashcam’s real-time
video.
2. Time Lapse Recording
Time lapse records a video at low frames at 1 / 2 / 3 / 5 /
10 fps, it keeps recording continuously without audio
recorded.
3. Low Bitrate Recording
This mode uses low bitrate to record video and audio,
and uses small file sizes for continuous recording.
Parking Mode
View on a TV
Note: Parking mode provides surveillance of your
parked vehicle only when the engine is off and the
USB Type-C Hardwire Kit is used to provide continuous
power.The Hardwire Kit also protects your car battery
from being drained. We recommend buying the
VIOFO HK4 ACC hardwire kit cable for parking mode
recording.
Note: The Micro HDMI port supports connecting to an
external monitor, with a minimum display resolution of
1920x1080P and a maximum resolution of 4K.
Note: Timelapse 1 fps mode supports Super Night Vision
option, which can provide brighter and clearer night
vision in extreme low light conditions, with lower power
consumption.
Playback Video on Dashcam
Playback and Manage Videos
Press the [ ] button to exit.
1.
2.
3.
Under standby mode (not recording), long press [ ]
button to enter the playlist.
22
23
Note:
Collision detection sensitivity can be adjusted in
settings under the “G-sensor” option. Locked files are
saved to microSD card: DCIM \ Movie \ RO
Disable / Enable Audio Recording
Pressing the [ ] button once to turn off / on audio
recording, [ ] LED light will be off / solid Blue.
