Viper 7900 - zone identification

41
© 2006 directed elect r o n i cs—all rights reser ved
Action Number of Chirps Description
Arm 1 System armed
Arm 1 (3-second delay), 1 System armed with
zone bypass
Disarm 2 System disarmed
Disarm 4 System disarmed with
trigger alert
Disarm 5 System disarmed NPC
active
➜
zone identification
This system has several inputs (or zones) that can trigger the alarm
while armed. Each zone input is identified by an icon on the remote
control and by groups of flashes by the status led.
Use the following table to identify each zone by icon and number, and
the sensor or vehicle circuit it is connected to.
