1.0 PROJECT & SYSTEM DESCRIPTION
1.1 Project Description
Project Name
Guidelines
Maximum flow rate
10, 20, or 30 GPM
Design dose
40, 80, or 120 mJ/cm
2
Operating pressure
15 psi (103 kPa) - 125 psi (862 kPa)
Ambient air temp.
0°C (32°F) - 40°C (104°F)
Ambient water temp.
2°C (35.6°F) - 40°C (104°F)
Hardness
120 ppm (7 grains / gallon) max.*
Manganese content
0.05 ppm max.*
Iron content
0.3 ppm max.*
UVT
75% min.*
*after pretreatment
1.2 System Description
Model
PRO10
PRO20
PRO30
Quantity
Chamber
Material
316L SST
Dimensions
21.4” x 4” (55 x 10 cm)
31” x 4” (78 x 10 cm)
41” x 4” (103 x 10 cm)
Inlet & outlet ports
Combo 1-1/4" MNPT, 1" FNPT
UL Certified burst
pressure
300 psi (2.067 MPa)
Orientation
Vertical
Integrated flow
restrictor
10 GPM (38 lpm) max. 20 GPM (76 lpm) max. 30 GPM (113 lpm) max.
Electrical
Power Supply
13” x 6.5” (33 x 16.5 cm)
Voltage
100 - 240 V AC
Frequency
50 - 60 Hz
Max. current
1.2 Amps
1.6 Amps
2.5 Amps
Max. power
consumption
120 Watts 160 Watts 230 Watts
Lamp power
100 Watts
140 Watts
200 Watts
Spare Parts
Quantity
Optional Accessories
Quantity
Lamps
COMMcenter™
Sleeves
Solenoid valve
UV sensors
4-20 mA Interface
Flowmeters
CoolTouch™ Fans
