Viscount Physis Organs Reference Manual
• Mixture Cancel
Data format: F0H 31H 2FH 6BH vvH F7H
F0H : Exclusive status
31H : Viscount ID
2FH : system control
6BH : mixture cancel
vvH : switch
00H=on
10H=off
F7H : EOX
• Cancel
Data format: F0H 31H 2FH 6CH 00H F7H
F0H : Exclusive status
31H : Viscount ID
2FH : system control
6CH : cancel
00H : execute cancel
F7H : EOX
• Couplers
Data format: F0H 31H 2FH 70H vvH F7H
F0H : Exclusive status
31H : Viscount ID
2FH : system control
70H : coupler
vvH : type and switch
00H=Swell to Pedal on
10H=Swell to Pedal off
01H=Great to Pedal on
11H=Great to Pedal off
02H=Choir to Pedal on
12H=Choir to Pedal off
03H=Swell to Great on
13H=Swell to Great off
04H=Choir to Great on
14H=Choir to Great off
05H=Swell to Choir on
15H=Swell to Choir off
F7H : EOX
- This message is received only.
Data format: F0H 31H 2FH 70H vvH ssH F7H
F0H : Exclusive status
31H : Viscount ID
2FH : system control
70H : coupler
vvH ssH:type and switch
04H 21H:Solo to Pedal on
04H 20H:Solo to Pedal off
14H 21H:Solo to Great on
14H 20H:Solo to Great off
24H 21H:Solo to Swell on
24H 20H:Solo to Swell off
34H 21H:Solo to Choir on
34H 20H:Solo to Choir off
02H 31H=Swell to Pedal 4’ on
02H 30H=Swell to Pedal 4’ off
03H 31H=Choir to Pedal 4’ on
03H 30H=Choir to Pedal 4’ off
12H 11H=Swell to Great 16’ on
12H 10H=Swell to Great 16’ off
12H 31H=Swell to Great 4’ on
12H 30H=Swell to Great 4’ off
13H 11H=Choir to Great 16’ on
13H 10H=Choir to Great 16’ off
13H 31H=Choir to Great 4’ on
13H 30H=Choir to Great 4’ off
14H 11H=Solo to Great 16’ on
14H 10H=Solo to Great 16’ off
22H 11H=Swell to Swell 16’ on
22H 10H=Swell to Swell 16’ off
22H 21H=Swell Unison Off on
22H 20H=Swell Unison Off off
22H 31H=Swell to Swell 4’ on
22H 30H=Swell to Swell 4’ off
32H 11H=Swell to Choir 16’ on
32H 10H=Swell to Choir 16’ off
32H 31H=Swell to Choir 4’ on
32H 30H=Swell to Choir 4’ off
24H 31H=Solo to Swell 4’ on
24H 30H=Solo to Swell 4’ off
F7H : EOX
- This message is received only.
• Orchestra volume
Parameter: Orch.
Video page: Volumes
Data format: F0H 31H 2FH 72H vvH F7H
F0H : Exclusive status
31H : Viscount ID
2FH : system control
72H : orchestra volume
vvH : orchestra volume value (00H – 7FH)
F7H : EOX
• Orchestral Voice Change
Data format: F0H 31H 2sH 41H xxH yyH iiH ttH
v1H v2H b1H b2H o1H o2H u1H u2H kkH F7H
F0H : Exclusive status
31H : Viscount ID
2sH : channel number (s=0H – EH)
41H : orchestral voice change
xxH : voice id – first byte
yyH : voice id – second byte
iiH: alternative voice id
ttH: timbre type
05H=single
06H=layer
07H=split
v1H: voice1/L volume
v2H: voice2/R volume
b1h: voice1/L brilliance
b2h: voice2/R brilliance
o1H: voice1/L octave shift
o2H: voice2/R octave shift
u1H: voice1/L sustain enable
u2H: voice2/R sustain enable
kkH: split key
F7H : EOX
- this message is transmitted only when an
alternative orchestral voices changes after
recalling a combination.
- with Single type, voice2 bytes are fixed to 40H
- with Single and Layer types, “split key” byte is not
used.
- after recalling a combination, if the orchestral voice
is setted as in the Organ Style, the message
change to:
F0H 31H 2sH 41H xxH yyH 00H 7FH 00H 00H
00H 00H 00H 00H 00H 00H 00H F7H
SYSTEM REAL TIME MESSAGES
FEH: Active Sensing
FEH is transmitted every 300 msec. whenever is no
other MIDI data being transmitted.
