APPENDICES
70 D-304829 PowerMaster-10/30 G2 User's Guide
PowerMaster-10 G2 PowerMaster-30 G2
(2) 7.2V 1300 mAh, rechargeable NiMH
battery pack, p/n 130AAM6BMX,
manufactured by GP or p/n LTT-
AA1300LSDX6B, manufactured by LTT.
(3) 9.6V 1800 mAh, rechargeable NiMH
battery pack, p/n GP180AAH8BMX,
manufactured by GP or p/n LTT-
AA1800LSDX8B, manufactured by LTT.
(4) 9.6V 2200 mAh, rechargeable NiMH
battery pack p/n 220AAH8BMX,
manufactured by GP or p/n LTT-
AA2200LSDX8B, manufactured by LTT.
Caution! Risk of explosion if battery is
replaced by an incorrect type. Dispose of
used batteries according to the
manufacturer's instructions.
Notes:
1. For compliance with CE standards the battery
backup period must be at least 12 hours.
2. For compliance with UL standards the battery
backup period must be at least 24 hours.
Note: Only the LTT-AA2200LSDX8B battery
pack is approved for use by UL.
Time to Charge
80 % (
13 Hrs) 80 % (
30 Hrs) for all battery types
Optional Backup
Battery Pack
See "Backup Battery Options" above See "Backup Battery Options" table above
Time to Charge
(optional backup
battery pack)
80 % (
24 Hrs)
NA
Wired Detectors
Total (Sum)
Current
NA 36* mA max.
Site External Siren
Current (EXT)
NA 450* mA max @ 12.5 VDC when powered by
AC/DC (10.5 VDC when in standby mode)
Site Internal Siren
Current (INT)
NA 450* mA max @ 12.5 VDC when powered by
AC/DC (10.5 VDC when in standby mode)
*
Total PowerMaster-30 G2 output current
(of INT & EXT sirens, PGM output and
detectors) cannot exceed 550 mA.
PGM Current sink to control panel GND 100 mA
max.
Max. external DC voltage +30 VDC
Current sink to control panel GND 100 mA
max.
Max. external DC voltage +15 VDC
High Current /
Short Circuit
Protection
NA All outputs are protected (automatic reset fuse)
E4. Communication
PowerMaster-10 G2 PowerMaster-30 G2
Communication PSTN; GSM; GPRS; IP (for future use) PSTN; GSM; GPRS; IP (for future use)
Built-in Modem 300 baud, Bell 103 protocol 300 baud, Bell 103 protocol
Data Transfer to
Local Computer
Via RS232 serial port Via RS232 serial port
Report
Destinations
2 Monitoring Stations, 4 private telephones 2 Monitoring Stations, 4 private telephones
Reporting Format
Options
SIA, Contact ID, Scancom, SIA IP, Visonic
PowerNet.
Note: For UL Listed product, the
communication formats used are SIA and
Contact ID.
SIA, Contact ID, Scancom, SIA IP, Visonic
PowerNet.
Note: For UL Listed product, the
communication formats used are SIA and
Contact ID.
Pulse Rate 10, 20, 33 and 40 pps - programmable 10, 20, 33 and 40 pps - programmable
