DLP Projector—User’s Manual
Views of Projector Parts
Front-right View
1
2
4 5
ITEM LABEL DESCRIPTION SEE PAGE
1.
IR receiver
Receive IR signal from remote control
2.
Lens Projection Lens
3.
Focus ring Focuses the projected image
4.
Zoom ring Enlarges the projected image
14
5.
Function keys
See Top view—On-screen Display (OSD) buttons
and LEDs.
3
Important:
Ventilation openings on the projector allow for good air circulation, which keeps the projector lamp
cool. Do not obstruct any of the ventilation openings.
— 2 —
