Vivitek DS262 - Page 24

22
Step
Figure
Description
4
Loosen the screw on
Lamp cover as shown.
5 Remove the lamp cover
6 1、Disconnect lamp
cable
2、Loosen the screws
on
lamp,then pull out the
lamp
3、Remove the
screw on
top cover as shown.
SCREW: J1635-B587-00
SCREW:J1635-3670-01
SCREW
SCREW:J1635-3670-01
