User's Manual - 111
support), 1(support)
Bit 3 => Support tilt operation; 0(not
support), 1(support)
Bit 4 => Support zoom operation;
0(not support), 1(support)
Bit 5 => Support focus operation;
0(not support), 1(support)
Bit 6 => Support iris operation;
0(not support), 1(support)
Bit 7 => External or built-in PT; 0(built-in),
1(external)
Bit 8 => Invalidate bit 1 ~ 7;
0(bit 1 ~ 7 are valid),
1(bit 1 ~ 7 are invalid)
Bit 9 => Reserved bit; Invalidate lens_pan,
Lens_tilt, lens_zoon, lens_focus, len_iris.
0(fields are valid),
1(fields are invalid)
protocol_https < boolean > 0/7 Indicate whether to support HTTP over SSL.
protocol_rtsp < boolean > 0/7 Indicate whether to support RTSP.
protocol_sip <boolean> 0/7 Indicate whether to support SIP.
protocol_maxconnection <positive integer> 0/7 The maximum allowed simultaneous
connections.
protocol_maxgenconnec
tion
<positive integer> 0/7 The maximum general streaming
connections.
protocol_maxmegaconn
ection
<positive integer> 0/7 The maximum megapixel streaming
connections.
protocol_rtp_multicast_
scalable
<boolean> 0/7 Indicate whether to support scalable
multicast.
protocol_rtp_multicast_
backchannel
<boolean> 0/7 Indicate whether to support backchannel
multicast.
protocol_rtp_tcp <boolean> 0/7 Indicate whether to support RTP over TCP.
protocol_rtp_http <boolean> 0/7 Indicate whether to support RTP over HTTP.
protocol_spush_mjpeg <boolean> 0/7 Indicate whether to support server push
MJPEG.
protocol_snmp <boolean> 0/7 Indicate whether to support SNMP.
protocol_ipv6 <boolean> 0/7 Indicate whether to support IPv6.
videoin_type 0, 1, 2 0/7 0 => Interlaced CCD
1 => Progressive CCD
2 => CMOS
