Installation
Hardware Installation
First, use a screwdriver to loose the three screws and detach the dome cover from the camera
base� Then, follow the steps below to install the camera to either a ceiling or a wall�
Ceiling mount with the bottom base
1� Attach the supplied alignment sticker to the ceiling�
2� Using the 10 circles on the sticker, drill 2 pilot holes symmetrically on each side into the ceil-
ing� Then hammer the four supplied plastic anchors into the holes�
3� Through the four holes on the bottom base, insert the four supplied screws into the corre-
sponding holes and secure the bottom base with a screwdriver�
4� Feed the cables through hole A or B� If you want to use hole B, remove the rubber stopper
with a screwdriver�
5� Secure the camera base to the bottom base with three supplied screws�
