Bottom Base
Outer View
Dome Cover
N.C.
N.C.
N.C.
AC24V
AC24V
Camera Base
a
b
c
Record the MAC address under
the camera base before installing
the camera�
Network Camera
Model No: FD7141
Made in Taiwan
This device complies with part 15 of the FCC rules. Operation is subject to
the following two conditions:
(1)This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference
that may cause undesired operation.
Pat. 6,930,709
RoHS
V I
MAC:0002D1083236
a
b
c
Hole a~c:
Holes for ceiling mount or for
attaching the bottom base�
