VIVOTEK
8 - User's Manual
IMPORTANT!
Installation
Removing Dome Cover
1
2
Semi-circular
cut-out
Slide cover
Release tab
1� Use one hand to hold the camera
bottom and another hand to hold the
dome cover� Press the release button�
2� Remove the dome cover�
3� Remove the slide cover if you want to
route cables from the side of camera
instead of a hole on the ceiling or wall�
0002D10766AD
2
1� Record the MAC address before installing the camera�
2. You can check the model name sufx for the type of lens mounted on your camera. The
applicable lens can be:
F2: 2.5mm; F3: 3.6mm; F6: 6mm; F8: 8mm; F12: 12mm. The shorter the focal length,
the wider the view�
It is recommended to use an Ethernet cable that comes without
the strain relief boot� You can remove the boot if your cable
comes with one�
Strain relief boot
NOTE:
