Vivotek FD8162 - Page 133

VIVOTEK
User's Manual - 133
crop_position <coordinate>
(x,y)
1/4 Crop left-top corner coordinate.
(not used in FD8162)
crop_size <window size>
(WxH)
1/4 Crop width and height.
(width must be 16x or 32x and height must be 8x)
(not used in FD8162)
crop_preview < boolean > 1/4 Usage for UI of crop setting
(not used in FD8162)
s<0~(m-1)>_code
ctype
mpeg4, mjpeg,
h264
<product
dependent>
1/4 Video codec type.
s<0~(m-1)>_resol
ution
Reference
capability_videoin
_resolution
1/4 Video resolution in pixels.
s<0~(m-1)>_mpe
g4_intraperiod
250, 500, 1000,
2000, 3000, 4000
4/4 Intra frame period in milliseconds.
s<0~(m-1)>_mpe
g4_ratecontrolmod
e
cbr, vbr 4/4 cbr, constant bitrate
vbr, fix quality
s<0~(m-1)>_mpe
g4_quant
1~5
99, 100
4/4 Quality of video when choosing vbr in
“ratecontrolmode”.
99 is the customized manual input setting.
1 = worst quality, 5 = best quality.
100 is percentage mode.
s<0~(m-1)>_mpe
g4_qvalue
2~31 4/4 Manual video quality level input.
(s<0~(m-1)>_mpeg4_quant = 99)
s<0~(m-1)>_mpe
g4_qpercent
1~100 4/4 Manual video quality level input.
(s<0~(m-1)>_mpeg4_quant = 100)
s<0~(m-1)>_mpe
g4_bitrate
1000~16000000
<product
dependent>
4/4 Set bit rate in bps when choosing cbr in
“ratecontrolmode”.
s<0~(m-1)>_mpe
g4_maxframe
1~25,
26~30 (only for
NTSC or 60Hz
CMOS)
1/4 Set maximum frame rate in fps (for MPEG-4).
s<0~(m-1)>_h264
_intraperiod
250, 500, 1000,
2000, 3000, 4000
4/4 Intra frame period in milliseconds.
s<0~(m-1)>_h264
_ratecontrolmode
cbr, vbr 4/4 cbr, constant bitrate
vbr, fix quality
s<0~(m-1)>_h264 1~5 4/4 Quality of video when choosing vbr in
_quant 99, 100 “ratecontrolmode”.
99 is the customized manual input setting.
1 = worst quality, 5 = best quality.
100 is percentage mode.
s<0~(m-1)>_h264
_qvalue
0~51 4/4 Manual video quality level input.
(s<0~(m-1)>_h264_quant = 99)
s<0~(m-1)>_h264
_qpercent
1~100 4/4 Manual video quality level input.
(s<0~(m-1)>_h264_quant = 100)
s<0~(m-1)>_h264
_bitrate
1000~16000000 4/4 Set bit rate in bps when choosing cbr in
“ratecontrolmode”.
s<0~(m-1)>_h264
_maxframe
1~25,
26~30 (only for
NTSC or 60Hz
CMOS)
1/4 Set maximum frame rate in fps (for h264).
s<0~(m-1)>_h264
_profile
<product
dependent>
0~2 1/4 Indicate H264 profiles
0: baseline
1: main profile
2: high profile
s<0~(m-1)>_mjpe
g_quant
1~5
99, 100
4/4 Quality of JPEG video.
99 is the customized manual input setting.
1 = worst quality, 5 = best quality.
100 is percentage mode.
s<0~(m-1)>_mjpe
g_qvalue
2~97 4/4 Manual video quality level input.
(s<0~(m-1)>_mjpeg_quant = 99)
s<0~(m-1)>_mjpe
g_qpercent
1~100 4/4 Manual video quality level input.
(s<0~(m-1)>_mjpeg_quant = 100)
s<0~(m-1)>_mjpe
g_maxframe
1~25,
26~30 (only for
NTSC or 60Hz
CMOS)
1/4 Set maximum frame rate in fps (for JPEG).
piris_mode manual, indoor,
outdoor
1/4 P-Iris mode.
piris_sensitivity 1~10 4/4 P-Iris sensitivity for indoor and outdoor mode.
piris_response 1~10 4/4 P-Iris response time for indoor and outdoor mode.
piris_position 1~100 1/4 P-Iris position for manual mode.
wdrc_mode 0~3 4/4 WDR enhanced.
0: off
1: auto
2: always on
3: keep current value
