Part 3: Installing the Cooler,
Bracket and Compressor
3.1 Installing the Oil Cooler
□ Remove lower primary coolant hose (attached to the primary
cooler and engine) (Figure 3.1).
To
Engine
From
Radiator
Figure 3.1
□ Cut the plastic cuff securing the OEM quick connect to engine
side coolant hose (discard OEM quick connect) (Figure 3.2).
Cut Cuff
OEM Quick
Connect
Figure 3.2
□ Cut the radiator side coolant hose 8” from the OEM quick
connect (discard short section of hose with OEM quick connect)
(Figure 3.3).
