Vmac VR70 - Part 5: Installing the Control Components

VMAC – Vehicle Mounted Air Compressors
Toll Free: 1-888-241-2289
Fax: 1-250-740-3201
55
Part 5: Installing the Control
Components
Figure 5.1
CONTROL BOX
RELAYS
START
HOT 12V
STOP
PARK ONLY, BLU
To OEM SEIC blue wire w/
grey stripe CLS05
DISPLAY
BOX
16
RED + BLK -
3 Amp
Fuse
4
4
Cut OEM wire Inside steering column Splice/solder joints
YEL
BLU
ORG
BLU
GRN-RED or BLU
-RED
BLU-WHT
Both go to OEM Ignition Switch Harness
To Hood Sw. 2 Pin Conn – GRY & BLK
To Clutch Bullet Conn
- WHT
DIGITAL GND, GRN-YEL To pin 3 Purple w/ green stripe
To AOST 3 pin BLK pressure connect
or
To Beacon 2 Pin Conn - GRY & RED
4
To Buzzer Ring Conn - BLK & RED
To Inlet 2 Pin Conn - BRN & RED
To Temp. Sensor 4 pin GRN Conn
OEM Connector
to accelerator
pedal
REMOTE ON
,
YEL
Connect to
accelerator
pedal
GROUND, GRN
-YEL
TACH, WHT
To OEM SEIC blue wire CE913
THROTTLE
CONTROLLER
PARK BRAKE, BRN
To OEM SEIC white wire w/ purple stripe
CMC25
ORG
IGN SW 12V, RED
To OEM SEIC yellow wire w/ orange stripe on early
builds or white wire w/ blue stripe on later builds
CDC64
Firewall
Diode
IGNITION CONNECTOR
IN STEERING WHEEL
4 7
YEL
BLU
ORG
ACCY
CAB TEMP
,
BLUE (2X)
