51
Part 4: Installing the Tank and
Hoses
4.1 Installing the Tank and Brackets
□ The tank (Figure 4.1) will mount to the passenger side frame rail
behind the suspension radius arm mount
Rear Tank Mount
Front Tank Mount
Suspension Radius Arm
Mount
Front
(Note: Tank Not Shown For Clarity)
Figure 4.1
Tank Clips &
3/8 x 4-1/2
Bolts
5/16 Nut &
Washer
3/8 Nut
5/16 x 2 Bolt &
Washer
5/16 x 1/2 Bolt &
Washer
5/16 x 1/2 Bolt &
Washer
Figure 4.2
□ Place the tank on a workbench with the front (oil filter end) of
the tank to your right and remove the oil filter
