3.6 Washer Bottle
□ Trace around passenger side front bumper support bracket where it
attaches to frame with a paint pen for alignment during reinstallation.
□ Remove bolts and nuts holding bumper support bracket to frame.
□ Install supplied check valve into hose attached to hood by the
windshield. Ensure arrow on check valve points in direction of
washer nozzles. Fitting pushes into hoses, (no clamps required).
□ Route supplied windshield washer hose from check valve, along
fender on fender liner and down to behind the bumper, (where the
bumper support mounts).
□ Drain OEM washer bottle, saving the fluid.
□ Remove the fill cap from the supplied washer bottle.
□ Remove and discard the cap retainer from the fill cap.
□ Attach the fill cap to the supplied fill fitting (Figure 3.25).
□ Install the bottle adaptor onto the washer bottle (Figure 3.25).
□ Install supplied carriage bolts through washer bottle mounting plate
and then attach washer bottle to plate using supplied M8 bolts and
nuts (Figure 3.25).
□
Up to 1” of the plastic brace, behind the bumper, can be
cut-off to help with installing the washer bottle and
bracket.
