Descriptions and Functions
VM-1 Receiver (optional accessory)
1. ANTENNA CONNECTORS - Connect each antenna to each connector.
2. CH1 VOL CONTROL - Turn this dial clockwise to increase the volume of wireless channel 1, turn
counter-clockwise to decrease.
3. RF LED - This LED will light when the wireless mic 1 is switched on.
4. POWER LED - This LED will light when the power is turned on.
5. AF LED - This LED will light when the wireless mic 2 is switched on.
6. CH 2 VOL CONTROL - Turn this dial clockwise to increase the volume of wireless channel 2, turn
counter-clockwise to decrease.
3
2
4 5
6
1
