TABLES & CHARTS
5/27/14
11-4
Condensing
Temp. °F
Entering Water
Temp. °F
Leaving Water
Temp. °F
Water Flow
gpm
Pressure
Drop
Average
Total Heat
of Rejection
100 50 110 9.5 0.9 275000
100 55 109 10 1.0 275000
100 60 108 12 1.3 275000
100 65 105 14 1.8 275000
100 70 103 17 2.7 275000
100 75 100 22 4.7 275000
100 80 97 34 11 275000
100 85 93 70 48 275000
105 90 95 110 119 275000
110 95 100 110 119 275000
Table 11-4
Condenser Water Usage
Cylinder Ice Crushed Ice
Make-Up Water Tube Size Tube Size
Temp. °F 1” 1 1/4” 1 1/2” 1” 1 1/4” 1 1/2”
40
2.56 2.25 2.19 3.00 2.62 2.54
50
2.49 2.21 2.14 2.92 2.58 2.49
60 2.42 2.16 2.09 2.84 2.53 2.43
70 2.35 2.12 2.04 2.74 2.47 2.38
80 2.14 1.93 1.86 2.49 2.25 2.16
90 1.93 1.74 1.68 2.25 2.02 1.94
Includes 10 gallons per cycle blowdown
Table 11-5
Make-Up Water Usage (gpm)
Suction Pressure
(psig)
Discharge Pressure
(psig)
Harvest Times
(secs)
Ice per
cycle
Freeze Time
(minutes)
End of Freeze Average during Freeze First All Ice Total
Average
Water Temperature (deg. F)
R22 R404A R22 R404A Ice Out Harvest
(lbs)
90 80 70 60 50
C
1" 34 45 200 240 15 120 150 235 17.9 16.0 14.4 13.9 13.5
Y
1 1/4" 32 42 200 240 15 120 150 245 21.0 18.8 17.0 16.6 16.2
60 L
1 1/2" 28 38 200 240 20 120 150 235 19.8 17.8 16.0 15.6 15.2
HZ C
1" 36 47 200 240 15 105 150 175 11.7 10.4 9.3 8.9 8.6
R
1 1/4" 34 45 200 240 15 105 150 175 13.7 12.1 10.9 10.6 10.3
U
1 1/2" 30 40 200 240 15 105 150 175 13.3 11.8 10.6 10.3 10.0
C
1" 34 45 200 240 15 120 150 235 17.9 16.0 14.4 13.9 13.5
Y
1 1/4" 32 42 200 240 15 120 150 245 21.0 18.8 17.0 16.6 16.2
50 L
1 1/2" 28 38 200 240 20 120 150 235 19.8 17.8 16.0 15.6 15.2
HZ C
1" 36 47 200 240 15 105 150 175 11.7 10.4 9.3 8.9 8.6
R
1 1/4" 34 45 200 240 15 105 150 175 13.7 12.1 10.9 10.6 10.3
U
1 1/2" 30 40 200 240 20 105 150 175 13.3 11.8 10.6 10.3 10.0
Table 11-6
Normal Operating Vitals

Vogt P18FXT Specifications
