Vogt P18FXT - Space Diagram (Water Cooled Machine)

10TA Service Manual
INSTALLING YOUR TUBE-ICE
®
MACHINE
4/14/14
3-3
6 5/16"
1'-1 1/2"
11 5/8"
10 1/16"
1/2" MPT MAKE-UP WATER
CONNECTION
6"
12" MINIMUM CLEARANCE FOR
INSTALLATION AND ACCESS
4'
5'
10'-4"
40" MINIMUM CLEARANCE FOR COMPRESSOR ACCESS
7'-9 7/8"
LIQUID
RETURN
LINE
7'-9 1/2"
DISCHARGE
LINE
1'-3 3/16"
1'-5 7/16"
2'-4 3/4"
1" WATER TANK
DRAIN LOCATED
ON RIGHT SIDE
REAR
LEFT SIDE
FRONT
ROTALOCK FIELD CONNECTOR PART# 12A2396A0501
1 1/4"-12 THREADS (F) X 1 1/8" IDS
ROTA-LOCK TEFLON SEAL PART# 12A2600T01
ROTALOCK FIELD CONNECTOR PART# 12A2396A0601
1 3/4"-12 THREADS (F) X 1 3/8" IDS
ROTA-LOCK TEFLON SEAL PART# 12A2600T03
FIELD ATTACHMENT AIR
COOLED CONDENSER TUBING
TOP VIEW
PROVIDE
SUFFICIENT SPACE
ICE DISCHARGE
40" MINIMUM CLEARANCE FOR WATER TANK ACCESS
1'-0 1/2"
FIELD
CONNECTIONS
FIGURE 3-2A
Connections and Space Diagram (Air Cooled Machine)
