Voice Systems Data Filer - System Connections Diagram

DATA FILER
4. CONNECTIONS
104
CAUTION!
ü
The Joy Port-to-MIDI adapter must have internal optoisolator.
ü If the Joy Port has an additional parallel connector on the adapter, this must not be
used for connecting peripherals.
