Livedrive V2
User Manual
6.0 Operating the Livedrive V2
6.1 Channel Select
- Using the CH Select +/- buttons, users can select the channel(s) to
control. This can be Input AB, CD, and Output 12, 34, 56, 78. When
link is selected off the inputs and outputs become uncoupled.
6.2 Input Menus
Each input channel has a set of Menus for specific parameters, accessed with the –
PAGE + / - buttons.
- Gain, -48.00dB (mute) to +12.00dB, in 0.25dB steps.
- Source, Analog, AES Channel A and B, AES Mono Sum, and AES
stereo
- Delay, 0ms to 2000ms in 0.01ms steps. Using the button on the control
wheel, units can be changed to feet or mm.
- Low Pass, 50Hz to 20kHz (off), in 1, 10, 50 and 100Hz steps. Using
the control wheel button, users can enable/disable it and change the
Filter Type.
- High Pass, 20Hz (off) to 20kHz, in 1, 10, 50 and 100Hz steps. Using
the control wheel button, users can enable/disable it and change the
Filter Type.
In AB Gain
0dB
In AB Delay
000.000ms
In AB LowPass
Freq: 80Hz
In AB HighPass
Type: BUT 24dB
In AB Source
Analog
