8.0 Specifications
Inputs 4 analog, 1 (2-Channel) AES, maximum input level +22dBu
Outputs 8 channels, maximum output level +12dBu
Frequency Response 20Hz – 30kHz
Dynamic Range >118 dB (unweighed) 20Hz – 20kHz
THD 0.002% (20 – 40kHz @ +4dBu)
Digital Processing 64-bit
A/D – D/A 24-bit
Compressor Gain: 0dB to 12dB
Hold: 0ms to 10,000ms
Threshold: 24dBu to -48dBu
Release: 1ms to 10,000ms
Attack: 1ms - 10,000ms
Ratio: 1.20:1 to Infinite
Crossover Slopes 6, 12, 18, 24 dB : Range 10Hz – 20kHz
Crossover Type Butterworth, Linkwitz-Riley, Bessel : HP – LP - Out
Output Limiters Threshold -48dBu to +12dBu
Attack Time : predictive
Release Time 10 – 100ms
Equalisation 10 EQ’s for each output, 10 EQ’s for each input
Bell filters with a Q of 0.20 to 25
Range 10Hz – 20kHz : Amplitude of ± 12dB
Hi & Lo Shelf filters
Fully adjustable Notch and Allpass filters
Input Compressors 1 fully adjustable compressor on each input
Delay Time Inputs up to 2000ms : Outputs up to 20ms
AES/EBU Input On AES input, accepting all clock speeds up to 192kHz
Connections Analogue XLR : AES/EBU XLR : USB PC link : Ethernet
Presets 100
Power Input IEC 230 VAC 50Hz
Dimensions:
Height 44 (mm) 1.75”
Width 483 (mm) 19”
Depth 167 (mm) 6.57”
Weight 2.37 (kg) 5.22lbs
