Livedrive V2
User Manual
- PEQ 1-10, 20Hz to 20kHz, in 1, 10, 50 and 100Hz steps. Gain from -
12dB to +12dB in 0.25dB steps. Q from 0.10 to 25 in 0.10 steps.
Change from Freq/Gain/Q with the control wheel button.
- Compressor, Threshold from 24dBu to -48dBu. Attack from 1ms to
10,000ms. Hold from 0ms to 10,000ms. Release from 1ms to
10,000ms. Ratio of 1.20:1 to Infinite and gain of 0dB to 12dB. Switch
between these by using the control wheel button.
- Limiter, -48.00dBu to +24.00dBu, in 0.25dBu steps. Using the control
wheel button, users can change the Release, from 10 to 100.
- Link, select whether inputs A/B are linked as a stereo pair.
6.3 Output Menus
Each output channel has a set of Menus for specific parameters, accessed with the
PAGE +/- buttons.
- Gain, -48.00dB (mute) to +12.00dB, in 0.25dB steps.
- Mixer, Input A-D -48dB to 0dB.
- Delay, 0ms to 2000ms in 0.01ms steps. Using the button on the control
wheel, units can be changed to feet or mm.
In AB PEQ XX
Q: 1.00
In AB Limiter
Thr.: 0dBu
In AB Link:
On
Out 1 Delay
00.000ms
In AB Compr.
Thr: 0dBu
Out 1 Mixer
Input A 0dB
In AB Gain
0dB
