- Low Pass, 50Hz to 20kHz (off), in 1, 10, 50 and 100Hz steps. Using
the control wheel button, users can enable/disable it and change the
Filter Type.
- High Pass, 20Hz (off) to 20kHz, in 1, 10, 50 and 100Hz steps. Using
the control wheel button, users can enable/disable it and change the
Filter Type.
- PEQ 1-10, 20Hz to 20kHz, in 1, 10, 50 and 100Hz steps. Gain from -
12dB to +12dB in 0.25dB steps. Q from 0.10 to 25 in 0.10 steps.
Change from Freq/Gain/Q with the control wheel button.
- Compressor, Threshold from 24dBu to -48dBu. Attack from 1ms to
10,000ms. Hold from 0ms to 10,000ms. Release from 1ms to
10,000ms. Ratio of 1.20:1 to Infinite and gain of 0dB to 12dB. Switch
between these by using the control wheel button.
- Limiter, -48.00dBu to +24.00dBu, in 0.25dBu steps. Using the control
wheel button, users can change the Release, from 10 to 100.
- Phase, can be normal or inverted polarity.
- Link, select whether outputs 1/2 are linked as a stereo pair.
Out 12 Link:
On
Out 1 Phase:
Normal
In AB LowPass
Freq: 80Hz
In AB HighPass
Type: BUT 24dB
In AB PEQ XX
Q: 1.00
In AB Compr.
Thr: 0dBu
In AB Limiter
Thr.: 0dBu
