VOLTCRAFT DSO4000B Series User Manual

Digital Storage Oscilloscope 45
To Make All Measurement
All measurement could measure all parameters of the current measurement source
and display the results on the screen.
Do the following steps to make all parameters measurement.
1. Press the [MEASURE] button on the front panel to enter the MEASURE function
menu.
2. Press the All Measure softkey to select ON.
3. Press the Source softkey to select the measure source (CH1~CH4,MATH, REFA,
REFB, REFC, REFD).
Options
Settings
Comments
Source
CH1~CH4
Select the measure source.
Measurement Type
1
Frequency
Calculate the waveform frequency by measuring
the first cycle.
2
Period
Calculate the time of the first cycle.
3
Mean
Calculate the arithmetic mean voltage over the
entire waveform.
4
Pk-Pk
Calculate the absolute difference between the
greatest and the smallest peaks of the entire
waveform.
5
CRMS
Calculate the Root Mean Square voltage over the
entire waveform.
6
PRMS
Calculate the actual RMS measurement of the first
complete cycle in the waveform.
7
Min
The most negative peak voltage measured over
the entire waveform.
8
Max
The most positive peak voltage measured over the
entire waveform.
9
Rising
Measure the time between 10% and 90% of the
first rising edge of the waveform.
10
Falling
Measure the time between 90% and 10% of the
first falling edge of the waveform.
11
+ Width
Measure the time between the first rising edge
and the next falling edge at the waveform 50%
level.
