VOLTCRAFT DSO4000B Series User Manual

Digital Storage Oscilloscope 46
12
- Width
Measure the time between the first falling edge
and the next rising edge at the waveform 50%
level.
13
+ Duty
Measure the first cycle waveform. Positive Duty
Cycle is the ratio between positive pulse width and
period.
14
- Duty
Measure the first cycle waveform. Negative Duty
Cycle is the ratio between positive pulse width and
period.
15
Base
Measure the highest voltage over the entire
waveform.
16
Top
Measure the lowest voltage over the entire
waveform.
17
Middle
Measure the voltage of the 50% level from base to
top.
18
Amplitude
Voltage between Vtop and Vbase of a waveform.
19
Overshoot
Defined as (Base - Min)/Amp x 100 %, Measured
over the entire waveform.
20
Preshoot
Defined as (Max - Top)/Amp x 100 %, Measured
over the entire waveform.
21
PMean
Calculate the arithmetic mean voltage over the
first cycle in the waveform.
22
FOVShoot
Defined as (Vmin-Vlow)/Vamp after the waveform
falling.
23
RPREShoot
Defined as (Vmin-Vlow)/Vamp before the
waveform falling.
24
BWidth
The duration of a burst measured over the entire
waveform.
25
Delay 1-2 ↑
The time between the first rising edge of source 1
and the first rising edge of source 2.
26
Delay 1-2 ↓
The time between the first falling edge of source 1
and the first falling edge of source 2.
27
LFF
The time between the first falling edge of source 1
and the last falling edge of source 2.
28
LFR
The time between the first falling edge of source 1
and the last rising edge of source 2.
29
LRF
The time between the first rising edge of source 1
and the last falling edge of source 2.
30
LRR
The time between the first rising edge of source 1
and the last rising edge of source 2.
