38
Repairs other than those described should only be carried out by an authori-
sed specialist. If you have queries about handling the measuring device, our
technical support is available under the following telephone number:
Voltcraft®, 92242 Hirschau, Lindenweg 15, Tel.-No. 0180 / 586,582 7.
Technical data
Display..........................................LCD; 11,000 counts
Measuring frequency....................approx. 4 measuring operations/second
Measuring cable length ................about 120 cm each
Automatic switch-off......................approx. 15 minutes
Operating voltage ........................9V block battery
Working conditions ......................0 to 50°C (<70%rh)
Operating altitude ........................max. 2,000 m
Storage temperature ....................-20°C to +60°C (<80%rh)
Ground DMM................................ca. 400 g
Dimensions (LxWxH)....................182 x 82 x 55 (mm)
Measurement tolerances
Statement of accuracy in ± (% of reading + display error in counts (= number of smallest points)). The
accuracy is valid for one year at a temperature of +23°C ± 5°C, and at a relative humidity of less than 70%,
non-condensing.
Resistance
Range Resolution Accuracy
110 Ω 0.01 Ω ±(1.2% + 0.5 Ω)
1.1 kΩ 0.0001 kΩ
11 kΩ 0.001 kΩ ±(1,2% + 8)
110 kΩ 0.01 kΩ
1.1 MΩ 0.0001 MΩ
11 MΩ 0.001 MΩ ±(2,5% + 8)
110 MΩ 0.01 MΩ
Overload protection 36 V/AC-DC
