Neutral Button
The gearshift function can be disconnected so that the
control lever only operates the throttle. The Neutral (N)
button (3) disengages the drive/reversing gear so that
engine speed may be increased without driving the
boat (warm-up mode).
The drive is disengaged.
The drive is engaged for movement ahead and
astern.
Single Lever Control
Single Lever Control is engaged by pressing the
button marked (4) in the picture. When the single lever
function is activated, the lever that is moved from its
position first becomes the control lever for all engines.
The other control lever has no function as long as the
single lever function is activated.
In order to activate the single lever function, the control
levers must be in Neutral (N) position.
Cruise control panel
Switch on cruise control by pressing the button.
Make fine adjustments to the locked engine speed by
pressing the + or – buttons to increase or reduce the
speed.
Docking Panel
When the boat is operated from a docking station,
engines can be stopped and started and messages
can be managed using the docking panel.
The joystick can be used for maneuvering when the
docking station is activated; refer to the Instruments
and Controls, page 59 section for further information.
Activation
Activate the helm station by depressing the on/off
button. Further pressure on the button locks the helm
station.
To switch off the function, hold the button down for 3
seconds.
Instruments and Controls
32 47713726 12-2021 © AB VOLVO PENTA
