1 Controls, steering shaft
Headlight high-low beam switch
Control up = Headlight flasher
Middle position = Low beams
Control down = High beam
Control, direction indicators
Lever forward = Right direction indicators
Lever backward = Left direction indicators
Horn
The horn sounds when the button is pressed in.
Windscreen wiper
Position J = Interval wiper (see below)
Position 0 = Neutral position, wiper off
Position I and II = Windscreen wiper (two speeds)
Ring pressed in = Washer with automatic wiping 3–4 strokes
Interval wiper:
It is possible to set the interval's time for interval wiping. The
interval time can be set to between 5 and 25 seconds. Proceed as
follows:
1 Turn the control to position J (interval wiper).
2 Turn back the control to position 0 (neutral position).
3 Wait the time that is desired as interval time, then turn the
control to position J again.
The interval time is the time that has passed between
deactivation of interval wiping until it was activated again, in
the interval 5 to 25 seconds.
Between 25 to 60 seconds, the interval time becomes 25
seconds.
If more than 60 seconds have passed between deactivation
and activation of interval wiping, the interval goes back to the
latest set interval time.
When the machine starts the interval time is 7 seconds.
2 Retarder pedal
The retarder pedal has two functions, engine brake and wheel
brake.
When the engine brake is activated, an engine brake active
symbol appears on the information display, see page
51
.
Other controls
Controls
127
