Cab
General
The cab is mounted on rubber pads, is insulated, and has a flat floor with rubber mat.
Tested and approved as safety cab. ROPS tested according to ISO 3471–2008 and FOPS tested according to
ISO 3449–2008.
Cab interior fittings and upholstery Fire-retardant (fire-resistant) measured according to ISO
3795-1989. Also meets MVSS 302.
Number of emergency exits 2 (right and left side window)
Heating and ventilation
The basic version of the machine is provided with an air conditioning system as well as a heating and ventilation
system with defrosting for all windows and best possible air distribution. The cab fan is a twin radial fan with
endless variable speed.
Engine and cab heater, diesel-powered (optional equipment)
Extra tank, volume (optional equipment) 39 l (10.3 US gal)
Output max. 12 kW
Fuel consumption max. 1.5 l/h (0.40 US gal)
Power consumption max. 86 W
Diesel grade
For temperatures down to -20 °C (-4 °F), use winter diesel according to DIN EN 590.
For temperatures between -20 °C (-4 °F) and -40 °C (-40 °F), use arctic diesel or polar diesel.
On machines with extra tank for engine and cab heater, the diesel can be mixed with kerosene if needed.
In special cases and at temperatures above 0 °C (32 °F), fuel oil according to DIN 51603 can be used.
Operator's seat
This machine is equipped with an operator's seat that
meets the criteria for EN ISO 7096 and EM1.
KAB Grammer (optional
equipment)
Height adjustment +23/-37 mm
(+0.9/-1.5 in)
±40 mm
(±1.6 in)
Suspension stroke (travel) ±62 mm
(±2.4 in)
±50 mm
(±2.0 in)
Fore-aft adjustment 160 mm
(6.3 in)
210 mm
(8.3 in)
Adjustment for operator's weight 50–150 kg
(110–331 lbs)
50–170 kg
(110–375 lbs)
Backrest adjustment (adjustable backrest angle) Forward 66°
Backward 72°
Forward 10°
Backward 70°
Upholstery Fire-resistant
Lap-type seatbelt with roller Yes
Three-point seatbelt No Option
Refrigerant
Type Quantity
GWP
(a)
R134a 1,35 kg (2.98 lb) 1931 CO
2
-eq
a) Global warming potential (GWP) is a measure of how much heat a gas
traps in the atmosphere relative to that of carbon dioxide (CO
2
). GWP is
calculated in terms of the 100–year warming potential of 1 kg of a
greenhouse gas relative to 1 kg of CO
2
.
422
Specifications
Cab
