9 Turn the front bogie wheels so that the lifting tools are
positioned as shown in the figure.
10 Lower the machine.
11 Apply the parking brake and turn the ignition to position 0.
12 Connect four lifting slings to the lifting tools. All lifting slings
should have the same length and be at least 8.5 m (27.9 ft).
13 Lift the machine using the lifting tools' lifting eyes.
14 Lower the machine carefully.
15 Disconnect the steering joint lock before moving the machine.
16 Remove the lifting tool before the machine is used. Store the
special nuts on the lifting tool's wire. Reinstall the original nuts.
Tightening torques, see
420
.
Lifting the machine
Storing wheel nuts on lifting tool
Operating instructions
Transporting machine
241
