Theft protection
Regarding: L60F, L70F, L90F
The purpose of the function is to prevent theft of the machine. The
function is activated with VCADS Pro.
When the anti-theft device is activated, a correct four-digit code
must be entered via the keyboard and the "SELECT" button
pressed before the engine can be started, the parking brake
released and a directional gear selected.
Selection and change of anti-theft code is done with the VCADS
Pro parameter ABQ. The code is stored in control units I-ECU and
V-ECU.
NOTE! When a starting attempt is made while the anti-theft device
is activated, the starter motor can crank the engine, but the engine
will not start.
The engine can be restarted without having to enter the code
within the delay time (VCADS Pro parameter FXZ).
Input signals
Conditions for output functions Output functions
- VCADS Pro parame‐
ter ABP
- VCADS Pro parame‐
ter ABQ
- VCADS Pro parame‐
ter FXZ
- Keyboard
- Key feed
- Time since latest
ignition switch Off
General conditions for the function
- VCADS Pro parameter ABP "On"
(activation of function)
- VCADS Pro parameter ABQ "****"
(anti-theft code)
- VCADS Pro parameter FXZ
(delay)
Deactivation of anti-theft device
- Ignition switch On (running position)
Display unit shows
Start lockout
Enter code ****
- Enter correct four-digit code via the keyboard and
then press "SELECT"
- The anti-theft device is
deactivated
The engine can now be
started, the parking brake
released and directional gear
selected.
Activation of anti-theft device
- Ignition switch Off (position 0) > VCADS Pro param‐
eter FXZ (delay time)
- Directional gear N
- Engine shutdown
- Parking brake applied,
MA5501 de-energised
(a)
a) Prevents operation of the parking brake via switch SW5501.
The following applies in case of faulty input signals:
Input signal
Assumed value in case of a fault
VCADS Pro parameter ABP “ON”
VCADS Pro parameter FXZ System default value
