38 INSTRUMENT; SENSOR;
WARNING AND INFORMATION
SYSTEM
380 General, common info about 383 -
387
Instruments
Regarding: L60F, L70F, L90F
Instrument panels, position
1015939
1
2
3
4
V1048999
Fig.12 Instrument panels
1 Front instrument panel (central instrument, switches, keypad for information display unit)
2 Roof panel (climate control system)
3 Pillar panel (mode selector, switches, ignition, hand throttle control, and electric power socket 12 V.)
4 Rear cab wall with electric power socket 24 V, hour meter, electrical distribution box with fuses and relays. Socket for
service tool.
33
